KTM 690 SMC R 2021 User Manual

TECHNICAL DATA 4
23
Screw, rear footrest bracket M8x16 25 Nm (18.4 lbf ft)
Screw, side stand bracket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, spring holder plate on side
stand bracket
M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, steering stem M8 20 Nm (14.8 lbf ft)
Screw, top triple clamp M8 17 Nm (12.5 lbf ft)
Engine carrying screw M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, engine bearer on frame M10 45 Nm (33.2 lbf ft)
Screw, handlebar support M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, side stand M10 35 Nm (25.8 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft)
Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft)
Loctite
®
243™
Lambda sensor M12x1.25 25 Nm (18.4 lbf ft)
Copper paste
Screw, swingarm pivot M12x1.5 80 Nm (59 lbf ft)
Nut, angle lever to link fork M14x1.5 100 Nm (73.8 lbf ft)
Nut, linkage lever to rocker arm M14x1.5 100 Nm (73.8 lbf ft)
Screw, radiator temperature sensor M18 20 Nm (14.8 lbf ft)
Screw, bottom steering head M20x1.5 60 Nm (44.3 lbf ft)
Loctite
®
243™
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft)
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft)

KTM 690 SMC R 2021 Specifications

General

Displacement	692.7 cm³
Bore x Stroke	105 mm x 80 mm
Power	55 kW (74 hp)
Torque	73.5 Nm
Compression Ratio	12.7:1
Starter	Electric starter
Transmission	6-speed
Fuel System	Electronic Fuel Injection
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 2 oil pumps
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Front Suspension	WP APEX 48
Rear Suspension	WP APEX with Pro-Lever linkage
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Front Tire	120/70 ZR 17
Rear Tire	160/60 ZR 17
Seat Height	890 mm
Ground Clearance	237 mm
Fuel Tank Capacity	13.5 liters
Engine Type	Single cylinder, 4-stroke
Front Brake	Brembo four piston radial caliper, brake disc
Rear Brake	Brembo single-piston floating calliper, brake disc
ABS	Bosch 9.1 MP (incl. Supermoto ABS)
Weight (without fuel)	147 kg
