16 ELECTRICAL SYSTEM
98
Preparatory work
Remove the passenger seat. ( p. 71)
V01203-11
Main work
Disconnect negative cable
1
from the 12 V battery to avoid
damaging the onboard electronics.
Remove positive terminal cover
2
.
F03612-01
Connect a battery charger to the 12-V battery. Connect the
battery charger to the mains connection.
Battery charger (58429074200)
It is impossible to overcharge the 12V battery using this bat-
tery charger.
This battery charger is not suitable for lithium-ion batteries.
Info
Charge the 12-V battery to a maximum of 10 % of the
capacity specified on the battery housing.
Disconnect the battery charger from the mains connection and
the 12-V battery after charging.
Guideline
The charging current, charging voltage, and charging time
must not be exceeded.
Recharge the 12-V battery
regularly when the motorcy-
cle is not being used
3 months
V01203-11
Mount positive terminal cover
2
.
Connect negative cable
1
to the 12 V battery.
Finishing work
Mount the passenger seat. ( p. 72)
Set time and date.
