COMBINATION INSTRUMENT 7
23
7.1 Combination instrument
F02743-10
The combination instrument is attached in front of the handlebar.
The combination instrument is divided into two function areas.
1
indicator lamps ( p. 24)
Display
2
7.2 Activation and test
F02754-01
Activation
The combination instrument is activated when the ignition is
switched on.
Info
The brightness of the displays is controlled by an ambient
light sensor in the combination instrument.
Test
The welcome text appears on the display and the indicator lamps
are briefly activated for a function check.
Info
The malfunction indicator lamp always lights up as long as
the engine is not running. If the engine is running and the
malfunction indicator lamp lights up, stop (taking care not
to endanger yourself or other road users in the process) and
contact an authorized KTM workshop.
The oil pressure warning lamp always lights up as long as
the engine is not running. If the engine is running and the
oil pressure warning lamp lights up, stop immediately (tak-
ing care not to endanger yourself or other road users in the
process) and switch off the engine.
The ABS warning lamp and TC indicator lamp light up until
a speed of approx. 6 km/h (approx. 4 mph) or more has
been reached.
7.3 Day-Night mode
F02744-01
Day mode is shown in a bright color.

KTM 890 DUKE R Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cc
Transmission	6-speed
Seat Height	834 mm
Dry Weight	166 kg
Front Suspension	WP APEX 43
Traction Control	MTC (Motorcycle Traction Control)
Power	121 hp (90 kW) @ 9, 250 rpm
Torque	99 Nm
Fuel Capacity	14 L
Rear Suspension	WP APEX Monoshock
Rear Brake	240 mm disc
ABS	Bosch 9.1 MP (Cornering ABS and Supermoto ABS)
Wheelbase	1, 482 mm
Front Brakes	2 x Brembo Stylema 4-piston radial calipers, 320 mm discs
Frame	Chromium-Molybdenum steel trellis frame
