SERVICE WORK ON THE CHASSIS 13
71
Warning
Danger of accidents Oil or grease on the brake discs
reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when nec-
essary.
– Clean and oil the dust boots and inner fork tubes of both fork
legs.
Universal oil spray ( p. 139)
– Press the dust boots back into their installation position.
– Remove excess oil.
Finishing work
– Take the motorcycle off the front lifting gear. ( p. 70)
– Remove the rear of the motorcycle from the lifting gear.
( p. 69)
13.6 Removing the passenger seat
K01359-10
–
Insert the ignition key in seat lock
1
and turn it clockwise.
– Raise the rear of the passenger seat cover, push it toward the
rear, and remove it upward.
– Remove the ignition key from the seat lock.
Info
The vehicle has been set up in the factory for one-
person operation. Only an authorized KTM workshop
may carry out the conversion.
The components for one-person operation and for oper-
ation with a passenger are included in the scope of
supply.
Always ensure that the legal requirements are observed,
e.g., entry in the vehicle documents if applicable.
