KTM 890 DUKE R User Manual

WHEELS, TIRES 15
87
15.2 Installing the front wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
K01367-11
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change front wheel bearing.
–
Clean and grease shaft seal rings
1
and contact surfaces
A
of the spacers.
Long-life grease ( p. 139)
K01368-10
–
Insert wide spacer
2
on the left in the direction of travel.
–
Insert narrow spacer
3
on the right in the direction of travel.
Info
Arrow
B
indicates the direction of travel of the front
wheel.
The wheel speed sensor wheel is on the left viewed in
the direction of travel.
K01369-10
–
Clean screw
4
and the wheel spindle.
– Grease wheel spindle lightly.
Long-life grease ( p. 139)
– Jack up the front wheel into the fork, position it, and insert the
wheel spindle.
–
Mount and tighten screw
4
.
Guideline
Screw, front
wheel spindle
M25x1.5 45 Nm (33.2 lbf ft)
Thread greased

KTM 890 DUKE R Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cc
Transmission	6-speed
Seat Height	834 mm
Dry Weight	166 kg
Front Suspension	WP APEX 43
Traction Control	MTC (Motorcycle Traction Control)
Power	121 hp (90 kW) @ 9, 250 rpm
Torque	99 Nm
Fuel Capacity	14 L
Rear Suspension	WP APEX Monoshock
Rear Brake	240 mm disc
ABS	Bosch 9.1 MP (Cornering ABS and Supermoto ABS)
Wheelbase	1, 482 mm
Front Brakes	2 x Brembo Stylema 4-piston radial calipers, 320 mm discs
Frame	Chromium-Molybdenum steel trellis frame
