Kubota ZD1021 - Specifications

3SPECIFICATIONS
ENGLISH
SPECIFICATIONS
Model ZD1011 ZD1021
Engine
Model D782-E4 D902-E4
Max. engine power (Gross) kW (HP) 14.4 (19.3) (*1)(*2) 16.1 (21.6) (*1)(*2)
Type Indirect injection, Liquid-cooled
Number of cylinders 3
Bore and stroke mm (in.)
67 x 73.6
(2.64 x 2.90)
72 x 73.6
(2.83 x 2.90)
Total displacement cm (cu. in.) 778 (47.5) 898 (54.8)
Rated revolution rpm 3200
Low idling revolution rpm 1400 to 1500 1450 to 1550
Fuel
Diesel fuel No. 2
Diesel fuel No. 1 [below -10 (14 )]
Starter Electric starter with battery, glow plug, 12 V, 1.2 kW
Lubrication Forced lubrication by trochoidal pump
Cooling Liquid with pressurized radiator
Battery 51R (12 V, RC: 80 min, CCA: 430 A)
Capacities
Fuel tank L (U.S.gals.) 23 (6)
Engine crankcase
(with filter)
L (U.S.qts.) 2.8 (3.0) 3.4 (3.6)
Engine coolant L (U.S.qts.) 2.7 (2.85)
Recovery tank L (U.S.qts.) 0.25 (0.26)
Transmission case including
Rear axle gear case
L (U.S.qts.) 7.5 (7.9) (*3)
Dimensions
Overall length mm (in.) 2230 (87.8) 2255 (88.6)
Overall width
w/o mower deck
mm (in.) 1210 (47.7) 1406 (55.4)
Overall
height
With ROPS
upright
mm (in.) 1890 (74.4)
With ROPS
folded
mm (in.) 1430 (56.3)
Wheelbase mm (in.) 1380 (54.3)
Min. ground clearance mm (in.)
130 (5.12)
W/48", W/54", W/60"
Tread
Front mm (in.) 890 (35.0) 1030 (40.6)
Rear mm (in.) 930 (36.6) 980 (38.6)
Weight
(W/MOWER DECK)
kg (lbs.) 588 (1296) with 48" 600 (1323) with 54" 630 (1389) with 60"
