7INSTRUMENT PANEL AND CONTROLS
ENGLISH
INSTRUMENT PANEL AND CONTROLS
ILLUSTRATED CONTENTS ILLUSTRATED CONTENTS
(1) Parking brake pedal............................. 11, 22 (10) Cutting height control dial..................... 28
(2) Parking brake lock pedal...................... 11, 22 (11) Key switch............................................ 13
(3) Lift lock lever........................................ 27 (12) Easy Checker (TM).............................. 14
(4) Motion control lever.............................. 11, 23 (13) Hour meter........................................... 15
(5) Seat belt............................................... 21 (14) PTO lever............................................. 30
(6) Cup holder............................................ - (15) Fuel gauge........................................... 15
(7) Operator's seat..................................... 21 (16) Coolant temperature gauge.................. 15
(8) ROPS................................................... 19 (17) Throttle lever........................................ 22
(9) Hydraulic lift control pedal.................... 22
