2 Installation
TracVision 4 is designed for simple installation and setup. Just
follow these easy steps:
Step Refer to Section...
1. Choose the hardware locations 2.1
2. Mount the Antenna Unit 2.2
3. Set the skew angle (Europe only) 2.2.1
4. Wire system components 2.3
5. Program the IRD (Europe only) 2.4
6. Install selected satellite pair 2.5.1
7. Load any user-selected satellites 2.5.2
8. Check out system 2.6
Materials and Equipment Required for Installation
• Electric drill
•
3
⁄8" (10 mm) drill bit and 3" (80 mm) hole saw
• Socket wrenches
• Flat tip and Phillips screwdrivers
• RG-6 (75 ohms) cable for a second RF signal cable
(if necessary)
• Crimp tool (LRC #L3011B or equivalent)
• Light hammer; center punch; tape; scriber/pencil
• Terminal lug crimping tool; wire strippers
• A PC with terminal emulation software such as
PROCOMM, Windows Terminal, or Windows
95/98 Hyperterminal
2-1
Installation
54-0150 Rev. E
Plan the entire installation before
proceeding! Take into account
antenna unit placement, running
cable distances between units, and
accessibility to the equipment after
installation. Cable lengths are
detailed in Table 2-2.
KVH recommends the use of
RG-6 (75 ohms) cable for RF
wiring. Use of non-RG-6
(75 ohms) cables will result in
degraded performance. The KVH
warranty does not cover degraded
performance due to improper
wiring.
Table 2-1
Installation Process
To Next Page
