5. ENGINE REMOVAL/INSTALLATION
ENGINE INSTALLATION
Install the engine in the reverse order of
removal. Install the engine to its original
position with a jack or other adjustable
support.
When installing the engine, do not
damage the bolt thread and route the
wires and cables properly.
• When installing the engine, be careful
to install the oil cooler pipes properly.
• Install the gear shift lever by align the
punch mark on the lever with that on
the spindle.
• Fill the crankcase to the proper level
with recommended engine oil.
•
After installation, perform the following
inspections and adjustments:
1. Throttle operation
2. Clutch lever free play adjustment
3. Drive chain adjustment
