3-19
Preparation before Use > Preparation for Sending a Document to a Shared Folder in a PC
In Windows 7
1 From [Start] button on the Windows, select [Control Panel], [System and Security], and
[Allow a program through Windows Firewall].
If the User Account Control dialog box appears, click the [Continue] button.
2 Configure the settings.
In Windows XP or Windows Vista
1 In Windows XP, from [Start] button on the Windows, select [Control Panel], and then
[Windows Firewall].
In Windows Vista, from [Start] button on the Windows, select [Control Panel], [Security],
and then [Turn Windows Firewall on or off].
If the User Account Control dialog box appears, click the [Continue] button.
2 Click the [Exceptions] tab and then the [Add port...] button.
3 Specify Add a Port settings.
Enter any name in "Name" (example: Scan to SMB). This will be the name of the new port.
Enter "445" in "Port Number". Select [TCP] for "Protocol".
4 Click [OK] button.
In Windows 10
1 Right-click [Start] button on the Windows and select [Control Panel], [System and
Security], and then [Allow an app through Windows Firewall].
If the User Account Control dialog box appears, click the [Continue] button.
2 Configure the settings.
Configuring Windows Firewall (page 3-15)
Configuring Windows Firewall (page 3-15)
