Kyocera ECOSYS P2035d Service Manual

2PG/2PH
2-3-5
Connector Pin No. Signal I/O Voltage Description
YC6 1 LED1 O 3.3/0 V DC Paper indicator display: On/Off
Connected
to the opera-
tion panel
PWB
2 LED2 O 3.3/0 V DC Jam indicator display: On/Off
3 SW I Analog Cancel key/GO key: On/Off
4SGND -- Ground
5 LED3 O 3.3/0 V DC Ready indicator display: On/Off
6 LED4 O 3.3/0 V DC Attention indicator display: On/Off
7 LED5 O 3.3/0 V DC Toner indicator display: On/Off
8 LED6 O 3.3/0 V DC Data indicator display: On/Off
YC304 1 +3.3V2 O 3.3 V DC 3.3 V DC power source
Connected
to the MP
paper sen-
sor
2 GND - - Ground
3 HANDSN I 0/3.3 V DC MP paper sensor: On/Off
YC305 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the main
motor
2PGND -- Ground
3 MMOTRDYN I 0/3.3 V DC Main motor ready signal
4 MMOTCLK O 0/3.3 V DC (pulse) Main motor clock signal
5 REMOTEN O 0/3.3 V DC Main motor: On/Off
YC306 1 +3.3V2 O 3.3 V DC 3.3 V DC power source
Connected
to the paper
sensor
2 GND - - Ground
3 PAPER I 0/3.3 V DC Paper sensor: On/Off
YC307 1 NC - - Not used
Connected
to the exit
sensor
2 +3.3V2 O 3.3 V DC 3.3 V DC power source
3SGND -- Ground
4 EXITN I 0/3.3 V DC Exit sensor: On/Off
YC308 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the regis-
tration
clutch,
paper feed
clutch and
developing
clutch
2 REGDRN O 0/24 V DC Registration clutch: On/Off
3 +24V3 O 24 V DC 24 V DC power source
4 FEDDRN O 0/24 V DC Paper feed clutch: On/Off
5 +24V3 O 24 V DC 24 V DC power source
6 DLPDRN O 0/24 V DC Developing clutch: On/Off
YC309 1 +24V3 O 24 V DC 24 V DC power source
Connected
to the MP
paper feed
solenoid
2 MPFDRN O 0/24 V DC MP paper feed solenoid: On/Off

Kyocera ECOSYS P2035d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PCL XL, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	544 MB
Sound power level (standby)	30.7 dB
Sound pressure level (printing)	53.3 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LED
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.1 W
Power consumption (printing)	535 W
Power consumption (PowerSave)	2.6 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
