2PG/2PH
1-2-6
1-2-5 Installing the network interface card (option)
Procedure
1. Turn off printer power switch.
Caution: Do not insert or remove network
interface card while printer power is on.
Doing so may cause damage to the printer
and the network interface card.
2. Open the rear cover.
Figure 1-2-8
3. Remove two screws and then remove the
optional interface slot cover.
4. Insert the network interface card into the
network interface slot. Push it in all the way.
5. Secure the network interface card by using
two screws.
Figure 1-2-9
Rear cover
To Next Page
