Code conversion
ABCDEF GHI J
0123456789
No. Items Description
(1) Engine ROM information [Flash ROM version]
(2) Boot ROM information [Boot ROM version]
(3) Software jumper switch
information
(hexadecimal)
[First byte/Second byte
(displayed in OEM model
only)]
First byte
bit 0 = 1: (Fixed)
bit 1 = 0: Overseas, 1: Domestic (Japan)
bit 2, 3 (Not used)
bit 4 = 0: Kyocera, 1: OEM
bit 5 = 0: For Europe, 1: For US
bit 6 = 0: Non MICR mode, 1: MICR mode
bit 7 (Not used)
Second byte: Displayed in OEM model only
(4) Tota l pa ge -
(5) Toner install information -
(6) USB information 00: Not connected
01: Full-Speed
02: Hi-Speed
(7) Operation panel lock sta-
tus (displayed only when
locked)
01: Partial lock
02: Full lock
(8) NVRAM error (displayed
only when any error has
occurred)
01: ID error
02: Version error
03: Checksum error
04: NVRAM crush error
(9) Printable area setting /Top offset/Left offset/Page length/Page width
(10) Left offset for each paper
source
/MP tray/Cassette1/Cassette 2/Cassette 3/Duplex
(1/600 inches unit)
(11) Top offset for each paper
source
/MP tray/Cassette 2/Cassette 3/Duplex
(1/600 inches unit)
(12) Offset for rotation /Top offset/Left offset/
(1/600 inches unit)
(13) Optional paper feeder ver-
sion
/Paper feeder 1/Paper feeder 2/
(14) Calibration table setting Setting value (FRPO I4), Hexadecimal
(15) Resolution Current value of bit-per-pixel
(16) Copy quantity -
(17) Installed device/function
information
bit0: HDD
bit1: Optional ROM
bit2: Memory card
bit3: USB memory
bit4: HDD security
(18) Operation panel message
language
PMSG command setting (decimal)
(19) Current temperature
0 to 50 C/32 to 122 F (in 1 C/1.8 F increment, “-” = Temperature sensor
is abnormal.)
