Kyocera ECOSYS P2035d Service Manual

2PG/2PH
1-4-15
(6)
Developing clutch
does not operate.
Broken developing clutch
coil.
Check for continuity across the coil. If none, replace the develop-
ing clutch.
Defective harness between
developing clutch and con-
trol PWB (YC308), or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective control PWB. Replace the control PWB (See page 1-5-19).
(7)
MP paper feed sole-
noid does not oper-
ate.
Broken MP paper feed sole-
noid coil.
Check for continuity across the coil. If none, replace the MP paper
feed solenoid.
Defective harness between
MP paper feed solenoid
and control PWB (YC309),
or improper connector
insertion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective control PWB. Replace the control PWB (See page 1-5-19).
(8)
Duplex solenoid does
not operate.
Broken duplex solenoid
coil.
Check for continuity across the coil. If none, replace the duplex
solenoid.
Defective harness between
duplex solenoid and control
PWB (YC317), or improper
connector insertion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective control PWB. Replace the control PWB (See page 1-5-19).
(9)
Eraser lamp does not
turn on.
Defective harness between
eraser lamp (YC701) and
control PWB (YC316), or
improper connector inser-
tion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
Defective eraser lamp
(PWB).
Replace the eraser lamp (PWB) (See page 1-5-32).
Defective control PWB. Replace the control PWB (See page 1-5-19).
(10)
Paper indicator is
flashing when paper
is present in the cas-
sette.
Defective paper sensor. Replace the paper sensor.
Defective harness between
paper sensor and control
PWB (YC306), or improper
connector insertion.
Reinsert the connector. Also check for continuity within the con-
nector harness. If none, remedy or replace the harness.
(11)
A paper jam in the
paper feed/convey-
ing section or fuser
section is indicated
when the power
switch is turned on.
A piece of paper torn from
paper is caught around reg-
istration sensor or exit sen-
sor.
Check and remove if any.
Defective registration sen-
sor on the high voltage
PWB.
Replace the high voltage PWB (See page 1-5-25).
Defective exit sensor. Replace the exit sensor.
(12)
Attention indicator is
lit when the top cover
is closed.
Defective interlock switch
on the power source PWB.
Check for continuity across the interlock switch. If there is no con-
tinuity when the interlock switch is on, replace the power source
PWB (See page 1-5-22).
Problem Causes Check procedures/corrective measures

Kyocera ECOSYS P2035d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PCL XL, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	544 MB
Sound power level (standby)	30.7 dB
Sound pressure level (printing)	53.3 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LED
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.1 W
Power consumption (printing)	535 W
Power consumption (PowerSave)	2.6 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
