Kyocera ECOSYS P6230cdn User Manual

9-10
Troubleshooting > Troubleshooting
Irregular horizontal lines
appear in the image.
― Select the [Menu] key > [Adjust/
Maintenance] > [Service] > [MC] and
increase the adjustment value. Increase
the adjustment value 1 level at a time
from the current value. If there is no
improvement after the value is
increased by 1 level, increase by 1 level
again. If there is still no improvement,
return the setting to the original value.
―
The altitude is 1000 m or
higher and irregular
horizontal white lines appear
in the image.
― Select the [Menu] key > [Adjust/
Maintenance] > [Service] > [Altitude
Adj.], and set to an elevation one level
higher than the current setting.
―
The altitude is 1000 m or
higher and dots appear in
the image.
― Select the [Menu] key > [Adjust/
Maintenance] > [Service] > [Altitude
Adj.], and set to an elevation one level
higher than the current setting.
―
Paper often jams. Is the paper loaded correctly? Load the paper correctly. page 3-2
Is the paper of the supported type? Is it
in good condition?
Remove the paper, turn it over, and
reload it.
page 3-4
Is the paper curled, folded or wrinkled? Replace the paper with new paper. page 3-4
Are there any loose scraps or jammed
paper in the machine?
Remove any jammed paper. page 9-26
2 or more sheets are
overlaps when ejected.
(multi feed)
― Load the paper correctly. page 3-2
Printouts are wrinkled. Is the paper loaded correctly? Load the paper correctly. page 3-2
Is the paper damp? Replace the paper with new paper. page 3-2
Symptom Checkpoints Corrective Actions
Reference
Page

Kyocera ECOSYS P6230cdn Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	6 s
Time to first page (color, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Duplex print speed (black, normal quality, A4/US Letter)	15 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Replacement cartridges	TK-5270Y, TK-5270C, TK-5270M, TK-5270K
Number of print cartridges	-
Page description languages	PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2100 sheets
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Legal, Letter, Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	RJ-45, USB 2.0
Optional connectivity	Wireless LAN
Storage media	HDD
Processor cores	2
Processor model	A9
Processor family	ARM Cortex
Maximum internal memory	1000 MB
Internal storage capacity	128 GB
Sound power level (standby)	30 dB
Sound pressure level (printing)	49.5 dB
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	56 W
Power consumption (standby)	0.6 W
Power consumption (printing)	466 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	532 mm
Width	390 mm
Height	409.5 mm
