Kyocera FS-1300D Service Manual

2H5/2HS
1-4-5
(3) Self diagnostic codes
Code Contents
Remarks
Causes Check procedures/corrective measures
0150 Control PWB EEPROM error
Detecting control PWB EEPROM (U300)
communication error.
Improper installa-
tion control PWB
EEPROM (U300).
Check the installation of the EEPROM
(U300) and remedy if necessary (See page
1-5-19).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
0420 Paper feeder communication error
Communication error between control
PWB and optional paper feeder.
Improper installa-
tion paper feeder.
Follow installation instruction carefully again.
Defective harness
between control
PWB (YC318) and
paper feeder inter-
face connector, or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).
Defective harness
between PF main
PWB (YC5) and
paper feeder inter-
face connector, or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective PF main-
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
2000 Main motor error
The main motor ready input is not given
for 2 s during the main motor is ON.
Defective harness
between main
motor (CN1) and
control PWB
(YC305), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission sys-
tem of the main
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective main
motor.
Replace the main motor (See page 1-5-29).
Defective control
PWB.
Replace the control PWB (See page 1-5-
19).

Kyocera FS-1300D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Processor model	PowerPC 405F5
Maximum internal memory	528 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Standard media sizes	105 x 148 mm - 215.9 x 297
Compatible operating systems	Windows, Mac OS X
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Maximum duty cycle	20000 pages per month
Display	LCD
Certification	TÜV/GS, CE, PTS
Power consumption (printing)	439 W
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1

Weight and Dimensions

Dimensions (WxDxH)	375 x 393 x 250 mm
