Kyocera FS-1920 Installation Guide

5
Installing the Waste Toner Box
The waste toner box is supplied with the printer. The waste toner box must be installed
in the printer.
1 Open the cap of the waste toner box.
2 Open the left cover on the left side of the
printer.
3 Insert the waste toner box as shown in
the figure. The box will be locked when
it fits into place.
STEP
4
Cap
Waste Toner
Box
Left Cover
FS-1920IG.book 5 ページ ２００４年１月１５日 木曜日 午前１０時２１分

Kyocera FS-1920 Specifications

General

Print Technology	Laser
Resolution	600 x 600 dpi
Warm-up Time	15 seconds
Time to First Page	9 seconds
Processor Frequency	200 MHz
Type	Monochrome Laser Printer
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Memory	32 MB
Output Capacity	250 sheets
