Chapter 3 Using the Operator Panel
3-43
Press the  or  key repeatedly until >Cassette
Size appears. The paper size is also displayed.
•Cassette3 Size > or Cassette4 Size > appears
when an option paper feeder (PF-70) is installed.
•Cassette3 Size > appears when an option paper
feeder (PF-75) is installed.
If option paper feeders are added,
Cassette1 Size
and
Cassette2 Size
will appear for the standard pa-
per cassette and Cassette3 Size
, and
Cassette4
Size
will appear for the option paper feeders.
Press the MENU key. The message display returns to
Ready.
Paper Size Unit Selection
The paper size unit (metric or inch system) used in the LCD
can be selected beforehand. At the time of Ready or when se-
lecting the size display, the unit for some paper may be re-
placed with the counterpart as shown in the following table.
For example, when placing the letter size paper in the cas-
sette while “mm” unit is selected. “A4” will be displayed in the
LCD. To correct the display, use the following procedures.
You can set the option paper feeder PF-70 using the same pro-
cedures, but when using the paper feeder PF-75, you cannot
select the paper size and unit.
Press the MENU key.
Press the  or  key repeatedly until Paper
Handling appears.
Press the  key.
Press the  or  key repeatedly until >Cassette1
size appears.
Press the  key. >>Unit appears.
Press the ENTER key. A blinking question mark (?)
appears.
Press the  or  key to select mm or inch.
Select mm or inch, and then, press the ENTER key.
Press the MENU key. The message display returns to
Ready.
Setting the Cassette Paper Type
Make this setting to match the paper type fed from the paper
cassette of the printer. If the paper type is set correctly, you
can perform printing using the media type selection function
from the application (printer driver). The factory default set-
ting is Plain. For more details about the paper types that can
be fed from the paper cassette, see
Paper Type on page 2-5 .
Press the MENU key.
Press the  or  key repeatedly until Paper
Handling > appears.
Press the  key.
Press the  or  key repeatedly until >Cassette 1
Type appears. The paper type also displayed.
>Cassette1 size
A4
NOTE
metric Inch
A3 Ledger (LD)
B4 Legal (LG)
A4 Letter (LT)
A4-R (A4) Letter-R (LT)
B5 Letter-R (LT)
B5-R (B5) Statement (ST)
A5 Statement (ST)
Folio Legal (LG)
( ) abbreviated display
Table 3-10
NOTE
Paper Handling >
4
5
1
2
>Cassette1 size
>>Unit
mm
>>Unit
? mm
Paper Handling >
>Cassette 1 Type
Plain
3
4
5
6
7
8
9
1
2
3
4

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
