Kyocera FS-C2026MFP+ User Manual

2MA/2MB
1-4-19
4202 Laser output error (cyan)
The pin photo signal is not
output from PD PWB C for
one second while laser is
emitted.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
APC PWB C and engine PWB (YC32)
Defective APC
PWB C.
Replace the laser scanner unit CY (see
page 1-5-45).
Defective PD PWB
C.
Replace the laser scanner unit CY (see
page 1-5-45).
Defective engine
PWB.
Replace the engine PWB (see page 1-5-27).
4203 Laser output error
(magenta)
The pin photo signal is not
output from PD PWB M for
one second while laser is
emitted.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
APC PWB M and engine PWB (YC31)
Defective APC
PWB M.
Replace the laser scanner unit KM (see
page 1-5-45).
Defective PD PWB
M.
Replace the laser scanner unit KM (see
page 1-5-45).
Defective engine
PWB.
Replace the engine PWB (see page 1-5-27).
4204 Laser output error (yellow)
The pin photo signal is not
output from PD PWB Y for
one second while laser is
emitted.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
APC PWB Y and engine PWB (YC32)
Defective APC
PWB Y.
Replace the laser scanner unit CY (see
page 1-5-45).
Defective PD PWB
Y.
Replace the laser scanner unit CY (see
page 1-5-45).
Defective engine
PWB.
Replace the engine PWB (see page 1-5-27).
4600 LSU cleaning motor error
When the LSU cleaning motor
is driven, the motor over-cur-
rent detection signal is
detected continuously for 50
times (5 s) at 100 ms inter-
vals.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
LSU cleaning motor and engine PWB
(YC36)
Defective drive
transmission sys-
tem of the LSU
cleaning motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
Defective LSU
cleaning motor.
Replace the LSU cleaning motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-27).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C2026MFP+ Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Media thickness	0.11 mm
Scan file formats	JPG, PDF, TIFF, XPS
Dimensions (WxDxH)	514 x 550 x 580 mm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows, Mac 10.4+, UNIX LINUX
PCL fonts	93
Digital sender	No
Maximum duty cycle	65000 pages per month
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, USB
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	25 ppm
Scan speed (color)	35 ppm
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	1300 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	1024 MB
Processor model	464
Processor family	PowerPC
Maximum internal memory	2048 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	16 W
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Sustainability certificates	ENERGY STAR
Certification	TÜV/GS, CE
