Kyocera FS-C2026MFP+ - Detaching and Refitting the DP Separation Pad

2MA/2MB
1-5-60
(3) Detaching and refitting the DP separation pad
Procedure
1. Remove the DP paper feed pulley unit
(see page 1-5-56).
2. Remove the DP separation pad.
3. Check or replace the DP separation
pad and refit all the removed parts.
Figure 1-5-93
DP separation pad
