Kyocera FS-C2026MFP+ - Remarks on Engine PWB Replacement

2MA/2MB
1-6-3
1-6-2 Remarks on engine PWB replacement
When replacing the engine PWB, remove the EEPROM (U1) from the engine PWB that has been removed
and then reattach it to the new engine PWB.
Figure 1-6-3
U1
EEPROM
Engine PWB
EEPROM
