Kyocera FS-C2026MFP+ User Manual

2MA/2MB
1-4-21
5304 Broken cleaning lamp Y
wire
When the cleaning lamp Y is
driven, the lamp over-current
detection signal is detected
continuously for 10 times (1 s)
at 100 ms intervals.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Drum unit Y and Drum relay PWB (YC5)
Drum relay PWB (YC1) and engine PWB
(YC34)
Defective cleaning
lamp Y.
Replace the drum unit Y. (see page 1-5-21).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-27).
6000 Broken fuser heater wire
The detected temperature of
fuser thermistor does not rise
1C/1.8F after the fuser
heater has been turned on
continuously for 10 s in warm-
ing up.
The fuser temperature does
not reach 100C/212F after
the fuser heater has been
turned on continuously for
30 s in warming up.
The detected temperature of
fuser thermistor does not
reach the specified tempera-
ture (ready indication temper-
ature) after the fuser heater
has been turned on continu-
ously for 60 s in warming up.
The detected temperature of
fuser thermistor does not rise
1C/1.8F after the fuser
heater has been turned on
continuously for 10 s during
printing.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser heater and power source PWB
(YC102)
Fuser unit and eject PWB (YC3)
Eject PWB (YC1) and engine PWB (YC19)
Deformed connec-
tor pin.
See page 1-4-22.
Defective triac. See page 1-4-22.
Fuser thermostat
triggered.
Reinsert the fuser unit (see page 1-5-26).
Broken fuser
heater wire.
Replace the fuser unit (see page 1-5-26).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-27).
6020 Abnormally high fuser
thermistor temperature
The fuser thermistor detects a
temperature higher than
240C/464F.
By the activation of the high
temperature error detection
circuit (230C/446F or more)
of fuser thermistor, the illumi-
nation of fuser heater was
forcibly turned off and 10 s
has elapsed.
Deformed connec-
tor pin.
See page 1-4-22.
Defective triac. See page 1-4-22.
Shorted fuser
thermistor.
Replace the fuser unit (see page 1-5-26).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-27).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C2026MFP+ Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Media thickness	0.11 mm
Scan file formats	JPG, PDF, TIFF, XPS
Dimensions (WxDxH)	514 x 550 x 580 mm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows, Mac 10.4+, UNIX LINUX
PCL fonts	93
Digital sender	No
Maximum duty cycle	65000 pages per month
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, USB
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (black)	25 ppm
Scan speed (color)	35 ppm
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	1300 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	1024 MB
Processor model	464
Processor family	PowerPC
Maximum internal memory	2048 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	50 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	16 W
Power consumption (standby)	79 W
Power consumption (average operating)	466 W
Sustainability certificates	ENERGY STAR
Certification	TÜV/GS, CE
