Kyocera FS-C5150DN

1-3
Machine Parts
14 Paper Transfer Unit
15 Paper Ramp
16 Duplex Unit
Components at the Rear of the Printer
17 Rear Cover
18 Rear Cover Lever
19 Network Indicators
20 Network Interface Connector
21 USB Interface Connector
22 USB Memory Slot (FS-C5250DN only)
23 Option Interface Slot
24 Power Cord Connector
25 Right Cover
26 Carrying Handles
16
15
14
1 2
17
18
20
19
21
22
23
24
25
26
26
