Kyocera KM-1635 - Page 205

2HA/2HB
2-4-3
Timing chart No.3 Paper feed from optional first paper feeder, single-side mode, original size A4/11" x 8 1/2", two sheets
DPFCL1*
*: Optional
120 ms
120 ms
RSW RM
YC8-9 YC4-4
DDM1* ESW
82 ms
200 ms
820 ms
1780 ms
1900 ms
1780 ms
82 ms
350 ms 350 ms
370 ms
420 ms
2020 ms
YC9-7 YC9-11 YC15-2
Primary feed Scondary feed Primary feed Scondary feed
Separation charging Transfer charging
