Kyocera KM-1635 - Main Body

2HA/2HB
1-2-4
1. Install the optional paper feeder as necessary .
1. Remove the eleven tapes.
Figure 1-2-3
2. Remove the two pins for light source unit.
Figure 1-2-4
1. Install the original cover or optional DP.
1. Install the optional duplex unit as necessary.
Install the optional paper feeder.
Remove the tapes and pins.
Tap es
Tap es
Tap es
Tap e
Tap es
Tap e
Pins
Install the original cover or the optional DP.
Install the optional duplex unit.
