Section Jam code Description Conditions
System 00 No paper feed When the power switch is turned on, the machine detects acti-
vation of the registration switch (RSW), the exit switch (ESW)
or the feedshift switch (FSSW).
04 Cover open JAM A cover open state is detected during copying.
05 Secondary paper feed tim-
eout
When the machine waits for secondary paper feed, 30 s or
more have elapsed.
Paper feed
section
10 No paper feed from the
MP tray
The registration switch (RSW) does not turn on within 1680 ms
of the MP paper feed clutch (MPPFCL) turning on; the clutch is
then successively held off for 1 s and turned back on once, but
the switch again fails to turn on within 1680 ms.
11 No paper feed from the
drawer 1
The registration switch (RSW) does not turn on within 1430 ms
of the paper feed clutch (PFCL) turning on; the clutch is then
successively held off for 1 s and turned back on once, but the
switch again fails to turn on within 1430 ms.
12 No paper feed from the
drawer 2* (first paper
feeder)
The registration switch (RSW) does not turn on within 2780 ms
of the drawer paper feed clutch 1 (DPFCL1)* turning on; the
clutch is then successively held off for 1 s and turned back on
once, but the switch again fails to turn on within 2780 ms.
13 No paper feed from the
drawer 3* (second paper
feeder)
The drawer feed switch 1 (DFSW1)* does not turn on within
2560 ms of the drawer paper feed clutch 2 (DPFCL2)* turning
on; the clutch is then successively held off for 1 s and turned
back on once, but the switch again fails to turn on within 2560
ms.
14 No paper feed from the
drawer 4* (third paper
feeder)
The drawer feed switch 2 (DFSW2)* does not turn on within
2560 ms of the drawer paper feed clutch 3 (DPFCL3)* turning
on; the clutch is then successively held off for 1 s and turned
back on once, but the switch again fails to turn on within 2560
ms.
15 Misfeed in vertical paper
conveying 1
The registration switch (RSW) does not turn on within 2340 ms
of drawer feed switch 1 (DFSW1)* turning on.
The drawer feed switch 1 (DFSW1)* does not turn off within
2050 ms of drawer feed switch 2 (DFSW2)* turning on.
The drawer feed switch 1 (DFSW1)* does not turn off within
2050 ms of drawer feed switch 2 (DFSW2)* turning off.
16 Misfeed in vertical paper
conveying 2
The drawer feed switch 1 (DFSW1)* does not turn on within
2050 ms of drawer feed switch 2 (DFSW2)* turning on.
Paper con-
veying sec-
tion
20 Multiple sheets in the MP
tray
The registration switch (RSW) does not turn off within 6320 ms
of registration switch (RSW) turning on.
The registration switch (RSW) does not turn off within 1680 ms
of MP paper feed clutch (MPPFCL) turning on.
21 Multiple sheets in the
drawer 1
The registration switch (RSW) does not turn off within 6320 ms
of registration switch (RSW) turning on.
The registration switch (RSW) does not turn off within 1430 ms
of paper feed clutch (PFCL) turning on.
22 Multiple sheets in the
drawer 2* (first paper
feeder)
The registration switch (RSW) does not turn off within 6320 ms
of registration switch (RSW) turning on.
The registration switch (RSW) does not turn off within 2780 ms
of drawer paper feed clutch 1 (DPFCL1)* turning on.
*: Optional.
