2JZ/2JX/2JV/2H7-1
2-2-3
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Engine PWB (EPWB) PARTS PWB ENGINE ASSY SP
2 Main PWB (MPWB) PARTS PWB MAIN ASSY SP
3 Power source PWB (PSPWB) PARTS UNIT LOW VOLTAGE
4 ISM PWB (ISMPWB) PARTS PWB ISM ASSY SP
5 ISC PWB (ISCPWB) PARTS PWB ISC ASSY SP
6 Inverter PWB (INPWB) PARTS UNIT LAMP INVERTER
7 CCD PWB (CCDPWB) -
8 Main operation PWB (OPWB-M) PARTS PWB PANEL MAIN ASSY SP
9 Right operation PWB (OPWB-R) PARTS PWB PANEL RIGHT ASSY SP
10 Left operation PWB (OPWB-L) PARTS PWB PANEL LEFT ASSY SP
11 Upper operation PWB (OPWB-U) OPERATION UPPER PWB ASS'Y
12 Front operation PWB (OPWB-F) OPERATION FRONT PWB ASS'Y
13 LCD PWB (LCDPWB) LCD OPERATION
14 LCD inverter PWB (LINPWB) LCD INVERTER
15 Main high voltage PWB (MHVPWB) PARTS UNIT HIGH VOLTAGE MAIN
16 High voltage control PWB (HVCPWB) PARTS PWB HVU CONTROL ASSY SP
17 Transfer high voltage PWB 1 (THVPWB1) PARTS UNIT HIGH VOLTAGE TRANSFER1
18 Transfer high voltage PWB 2 (THVPWB2) HVU TRANSFER 2
19 Main front PWB (FRPWB-M) PARTS PWB FRONT MAIN ASSY SP
20 Sub front PWB (FRPWB-S) PARTS PWB FRONT SUB ASSY SP
21 Feed PWB (FPWB) PARTS PWB FEED ASSY SP
22 Motor control PWB (MCPWB) PARTS PWB MOTOR CONTROL ASSY SP
23 Drum PWB M (DRPWB-M) -
24 Drum PWB C (DRPWB-C) -
25 Drum PWB Y (DRPWB-Y) -
26 Drum PWB K (DRPWB-K) -
27 Encoder PWB M (ECPWB-M) -
28 Encoder PWB C (ECPWB-C) -
29 Encoder PWB Y (ECPWB-Y) -
30 Encoder PWB K (ECPWB-K) -
31 Developing PWB M (DEVPWB-M) -
32 Developing PWB C (DEVPWB-C) -
33 Developing PWB Y (DEVPWB-Y) -
34 Developing PWB K (DEVPWB-K) -
35 APC PWB M (APCPWB-M) -
36 APC PWB C (APCPWB-C) -
37 APC PWB Y (APCPWB-Y) -
38 APC PWB K (APCPWB-K) -
39 PD PWB (PDPWB) -
40 Waste toner full PWB (WTFPWB) PRINTED W.BOARD TONER FULL ASSY
41 Transfer belt speed PWB (TBSPWB) -
42 JAM LED PWB 1 (JLEDPWB1) PARTS PWB LED ASSY SP
43 JAM LED PWB 2 (JLEDPWB2) PARTS PWB LED ASSY SP
44 Interface PWB (IFPWB) PARTS PWB KUIO IF ASSY SP
45 Fax control PWB (FCPWB) -
