2JZ/2JX/2JV/2H7
1-3-47
U091
Setting the white line correction
Description
Sets the error detection threshold value for white line correction and displays the count result of abnormal pix-
els.
Purpose
To perform when replacing the CIS or DP driver PWB.
Method
1. Press the start key.
2. Press [EXECUTE].
3. Press the start key. Holding of white reference data is started.
4. The count result of abnormal pixels is displayed.
Setting: Threshold value setting
1. Select the item to be set.
2. Change the value using the +/- or numeric keys.
3. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
Calculation(R) Abnormal pixel count result for color R
Calculation(G) Abnormal pixel count result for color G
Calculation(B) Abnormal pixel count result for color B
Display Description Setting range Initial setting
Threshold(R) Setting of abnormal pixel detection thresh-
old value for color R
0 to 1023 112
Threshold(G) Setting of abnormal pixel detection thresh-
old value for color G
0 to 1023 112
Threshold(B) Setting of abnormal pixel detection thresh-
old value for color B
0 to 1023 112
Abnorm Pixel
Threshold
Abnormal pixel threshold value setting 0 to 8191 75
MODE Switching between white line correction
mode ON/OFF
0: OFF
1: ON
2: Test mode
0
To Next Page
