17
Reference: Once stored set value is maintained even after the power is cut off.
Note: Selecting operation pattern is enabled when ‘Pattern Select Command 1’ or ‘Pattern Select
Command 2” of external control input is set to OFF.
Reference: Operation pattern is selected by giving priority to the external control input. When it is
selected by the external control input, set value of Function ‘F-14’ is cancelled to have the
initial value ‘0.’
3-6 PATTERN FUNCTION
High and low limit values are stored in 4 sets of operation patterns (0 to 3). They can be changed from external
control input terminal or by key operation.
1) Writing to Operation Patterns of High/Low Limit Values
When pattern No. (0 to 3) is displayed on the Status Indicator ([STATUS]) on the front panel, the preset
high or low limit values are stored as patterns 0 to 3.
2) Selecting Operation Pattern
• Operation pattern can be selected by setting function selecting mode ‘F-14.’
For operation procedures, see function selecting mode ‘F-14.’
• Operation pattern is selected by ‘Pattern Select Command 1’ or ‘Pattern Select Command 2’ of the external
control input.
Pattern Select Command 1 Pattern Select Command 2
Operation pattern 0 Open (OFF) Open (OFF)
Operation pattern 1 Close (ON) Open (OFF)
Operation pattern 2 Open (OFF) Close (ON)
Operation Pattern 3 Close (ON) Close (ON)
3-7 LEVEL TEST FUNCTION
Level test function is used for setting the indication of the WGI-400A to a predetermined indicated value. It is
used for adjusting the external connected devices or testing the output of the WGI-400A.
1) Setting Function
• Additional Function
0 disabled: Displays the indicated value irrespective of the measured value.
1 enabled: Displays the indicated value by adding the set value to measured value.
• Setting level test value
Level test value is set within the range ±9999 and the initial value shall be 1000.
For how to set the level test value, see function selecting mode ‘F-25.’
2) Operation
Set value is continuously displayed while the level test command of the control input is set to close (ON).
To Next Page
