Rigging system description
Seventeen holes are available for site angle adjustment. They are compatible with Ø12 mm shackles WLL 1 t (two
provided).
A15i-LIFT pickup point
Select the same pickup point on each A15i-LIFT within an array of up to 6 enclosures.
For larger arrays, refer to Radial arrays of 7 enclosures and more (p.112).
1 2
3
4
5
6 7 8 9 10
11 12
13
14
15 16
17
FRONT
A15iFOCUS-SCREEN-LIFT and A15iWIDE-SCREEN-LIFT are dedicated screens for A15i Wide/Focus enclosures on which
A15i-LIFT is secured.
A15i owner's manual (EN) version 1.0 33
