32 FP+ Series Operation Manual
9 TEChNICAL sPECIFICATIONs
Following are the FP+ Series technical specifications. These figures are accurate at the time of printing but
please note that all figures are subject to change without notice. For the most accurate and current information
available, please visit www.labgruppen.com.
Model
Number of channels
Peak total output all channels driven
Peak output voltage per channel
Max. output current per channel
Max. Output Power
16 ohms per ch. (all ch.’s driven)
8 ohms per ch. (all ch.’s driven)
4 ohms per ch. (all ch.’s driven)
2 ohms per ch. (all ch.’s driven)
16 ohms Bridged per ch.
8 ohms Bridged per ch.
4 ohms Bridged per ch.
2 ohms Bridged per ch.
Performance with Gain
THD 20 Hz - 20 kHz for 1 W
THD at 1 kHz and 1 dB below clipping
Signal To Noise Ratio
Channel separation (Crosstalk) at 1 kHz
Frequency response (1 W into 8 ohms) +0/-3 dB
Input Impedance
Input Common Mode Rejection, CMR
Output impedance @ 100 Hz
Output slew rate into 8 ohms
Voltage Peak Limiter (VPL), max. peak output
VPL, selectable per ch. (V)
VPL, selectable when bridged (V)
1)
Voltage Peak Limiter mode (per ch.) Hard / Soft
Gain and Level
Amplifi er gain selectable (all channels)
1)
– rear-panel switches
23, 26, 29, 32, 35, 38, 41, 44 dB
Default gain 38 dB 38 dB 35 dB 35 dB
Level adjustment (per ch.) Front-panel potentiometer, 21 position detented from -inf to 0 dB
Connectors and switches
Input connectors (per ch.) 3-pin XLR, electronically balanced
Output connectors (per ch.) Neutrik Speakon or Binding Posts (must be specified upon order). BP only on FP 13000
Output bridge mode per two ch.’s A+B - Ch. A is signal input source. A+B, C+D - Ch.’s A and C are input source
NomadLink
®
network
2 x RJ45 Ethercon connectors, IN and OUT
Intelligent fans (on/off) Yes, depending on presence of output signal
Power on/off and Remote enable on/off Individual switches on front-panel
Cooling Two fans, front-to-rear airfl ow, temperature controlled speed
Front-panel indicators
Common NomadLink
®
Network; Power Average Limiter (PAL)
2)
; Power on
Per channel Signal present / High-impedance; -20 dB, -15 dB, -10 dB and -4 dB output
signal; Voltage Peak Limiter (VPL); Current Peak Limiter (CPL):
Very High Frequency (VHF); High temperature; Fault; Mute
Power
Operating voltage, 230 V / 115 V nominal
4)
130-265 V / 65-135 V
Minimum power-up voltage, 230 V / 115 V 171 V / 85 V
Power Average Limiter (PAL)
2)
Yes
Soft start / Inrush Current Draw Yes / max. 5 A
Mains connector 230 V CE: 16 A, CEE7; 115 V ETL: 30 A Twist lock
Dimensions (W/H/D)
W: 483 mm (19”), H: 88 mm (2 U), Overall D: 396 mm (15.6”), Mounting D: 358 mm (14.1”)
Weight
12 kg (26.4 lbs.)
Finish
Black painted steel chassis with black painted steel / aluminum front
Approvals
CE, ANSI/UL 60065 (ETL), CSA C22.2 NO. 60065, FCC
Note 1): Automatic -6 dB gain compensation when bridging channels.
Note 2): PAL can reduce the maximum output power to keep the power supply operating safely, and/or to prevent excessive current draw tripping the mains breaker.
Refer to Operation Manual.
Note 3): The amplifier will be fully operational at bridge-mode 2 ohm loads, but due to physical constraints in the construction, the max. output power will not be
significantly higher than running individual channels and therefore not stated here.
Note 4): Separate 230 V or 115 V versions available. Not selectable on the amplifier.
All specifications are subject to change without notice.
FP 13000 FP 7000 FP 10000Q FP 6000Q
2 2 4 4
13000 W 7000 W 10000 W 6000 W
195 V 155 V 150 V 101 V
58 Arms 42 Arms 38 Arms 27 Arms
1200 W 730 W 660 W 320 W
2350 W 1450 W 1300 W 625 W
4400 W 2800 W 2100 W 1250 W
6500 W 3500 W 2500 W 1500 W
4700 W 2900 W 2600 W 1250 W
8800 W 5600 W 4200 W 2500 W
13000 W 7000 W 5000 W 3000 W
3) 3) 3) 3)
35 dB and VPL: 195 V 35 dB and VPL: 155 V 35 dB and VPL: 150 V 35 dB and VPL: 101 V
0.1% 0.1% 0.1% 0.1%
0.05% 0.05% 0.05% 0.05%
112 dBA 112 dBA 112 dBA 112 dBA
70 dB 70 dB 70 dB 70 dB
6.8 Hz - 34 kHz 6.8 Hz - 34 kHz 6.8 Hz - 34 kHz 6.8 Hz - 34 kHz
20 kOhm 20 kOhm 20 kOhm 20 kOhm
54 dB 50 dB 45 dB 50 dB
19 mOhm 19 mOhm 56 mOhm 56 mOhm
20 V/microsecond 20 V/microsecond 20 V/microsecond 20 V/microsecond
195, 170, 140 , 116, 10 0,
80, 66, 54 V
155, 121, 101, 83, 70,
56, 47, 38 V
150, 121, 101, 83, 70,
56, 47, 38 V
101, 83, 70, 56, 47,
38 V
390, 340, 280, 232,
200, 160, 132, 108 V
310, 242, 202, 166,
140, 112, 94, 76 V
300, 242, 202, 166,
140, 112, 94, 76 V
202, 166, 140, 112,
94, 76 V
