Lab.gruppen FP+ series User Manual

FP+ Series Operation Manual 11
QUICK GUIDE OVERVIEW 6
6.2 Rear-Panel overview
SPEAKER OUTPUTS
BALANCED INPUTS
CH DCH D CH C+D CH B CH B CH A+BCH C CH A
XLR
PIN 1-SCRN PIN 2-POS PIN 3-NEG
44dB
41dB
38dB
35dB
32dB
29dB
26dB
23dB
150V
121V
101V
83V
70V
56V
47V
38V
BRIDGE
1+:+
2- : -
1+ CH D+
1- CH D-
1+ CH C+
1- CH C-
2+ CH D+
2- CH D-
1+ CH B+
1- CH B-
1+ CH A+
1- CH A-
2+ CH B+
2- CH B-
Ser. N:o
Removed!
WIRING
NORMAL: CLASS 2
BRIDGED: CLASS 3
Must be grounded/earthed
Made in Sweden
200-240V 50-60Hz :2500W
FP 10000Q
DIP switches
for adjusting key
features
(See below)
XLR connectors for
inputs and loop thru
Mains input 115V or
230V operation
(Not selectable)
NomadLink
network In and Out
on EtherCon housed
RJ45 connections
4 channel version
shown with Neutrik
Speakon output
connectors
Rear view of 2-channel model fitted with Binding Post connectors
Rear view of 2-channel model fitted with Speakon connectors
Rear view of 4-channel model fitted with Binding Post connectors
SPEAKER OUTPUTS
BALANCED INPUTS
CH DCH D CH C+D CH B CH B CH A+BCH C CH A
XLR
PIN 1-SCRN PIN 2-POS PIN 3-NEG
44dB
41dB
38dB
35dB
32dB
29dB
26dB
23dB
150V
121V
101V
83V
70V
56V
47V
38V
BRIDGE
1+:+
2- : -
1+ CH D+
1- CH D-
1+ CH C+
1- CH C-
2+ CH D+
2- CH D-
1+ CH B+
1- CH B-
1+ CH A+
1- CH A-
2+ CH B+
2- CH B-
Ser. N:o
Removed!
WIRING
NORMAL: CLASS 2
BRIDGED: CLASS 3
Must be grounded/earthed
Made in Sweden
200-240V 50-60Hz :2500W
FP 10000Q
Rear view of 4-channel model fitted with Speakon connectors

Lab.gruppen FP+ series Specifications

General

Series	FP+
Total Harmonic Distortion	<0.1%
Damping Factor	>500
Dimensions	88mm x 483mm x 400mm (HxWxD)
Weight	12.5kg
Type	Amplifier
Output Voltage	Varies by model
Input Impedance	20 kOhm balanced
Gain	32dB
Power Consumption	Varies by model
Power Output	2 x 1300W @ 4Ω, 2 x 800W @ 8Ω
Power Supply	Universal, regulated switch mode power supply
