In the design variant the auto-
matic check is not provided.
Thereupon, proper functionality con-
firmation is checked through testing
as follows: press the daily mileage
counter reading reset button (18),
without the button release, switch on
the ignition, release the button – the
signal indicators, LCD display and
the instruments should actuate for
25 seconds. No alarm signal indica-
tor flashing or its subsequent actua-
tion in the intermittent duty indicates
that the circuit check is necessary.
The vehicle operation with faulty
signal indicator is unacceptable.
When the coolant operating temper-
ature is exceeded (above 115
0
С) it
flashes red consistently.
With the engine running
When the coolant operating tem-
perature is exceeded (above 115
0
С)
it flashes red consistently and the
intermittent buzzer beep is actuated
for a short time. The temperature
light signal indicator in the intermit-
tent duty indicates the coolant tem-
perature sensor circuit failure. Do
not run the engine in overheat
condition.
ATTENTION!
The vehicle operation with
overheated engine is not allowed.
The vehicle must be delivered to
the certified SSNE to trou-
bleshoot the cause of the engine
overheating.
8 – «Brake failure» signal indi-
cator. It flashes red when switching
on the ignition for about 2 seconds
and it goes out at the end of ABS self-
test mode (in the design variant).
The signal indicator blinking mode
indicates that the parking brake is
switched on. Consistently flashing
signal indicator indicates the low
brake fluid level in the hydraulic brake
actuation tank or the failure of ABS
Electronic Brake-force Distribution.
(in this case, it is switched on togeth-
er with the ABS signal indicator).
With the engine running, the sig-
nal indicator actuation is duplicated
with a short intermittent buzzer beep.
Warning
The vehicle operation with con-
stantly flashing signal indicator is
not allowed. In this case, you
should contact any certified SSNE.
9 – right turn signal indicator. It
flashes green when the right turn sig-
nal indicators are switched on.
10 – storage battery discharge
signal indicator. It flashes red when
switching the ignition on and goes
out after the engine starting.
With the engine running, light
emission of the signal indicator and
intermittent beep of the buzzer mean
the abnormal operation of the power
supply system and indicate a fault in
the storage battery charging system,
low tension or the rupture of alterna-
tor drive belt, or fault in the alternator.
ATTENTION!
In this case, you should con-
tact any certified SSNE.
11 – speedometer. It indicates
the vehicle speed (km/h).
12 – ESC (in the design vari-
ant). The Electronic Stability Prog-
ram (ESC) signal indicator. It flashes
orange when switching on the igni-
tion for about 2 seconds and it goes
out at the end of the ABS-ESC sys-
tem self-test mode. During the vehi-
cle driving it flashes and blinks with a
frequency of 2-3 times per second in
case of the electronic stability con-
trol or anti-skid function actuation.
The ESC OFF signal indicator flash-
es orange after the electronic stabili-
ty control and anti-skid functions dis-
abling and it goes out after these
functions enabling.
38
