89
F1 15А Ignition coil
Nozzles
EMS control unit
F2 30A Body electronics mainframe
F3 10А Body electronics mainframe
Warning light switch
F4 15А Air bags controller
Rain sensor
F5 7,5А Terminal clamp – 15 devices
F6 7,5А Backup light
Backup light relay
Parking Assist System control unit
F7 7,5А Adsorber blowdown valve
Mass airflow sensor/pressure sensor
Phase sensor
Oxygen sensor
Tire Pressure Monitoring System control unit
F8 Reserve
F9 5А Right side parking lights
F10 5А Left side parking lights
Instrument panel and buttons illumination
License plate lamp
Trunk compartment lamp
Glove box lamp
F11 5А Rear fog light
F12 10А Low beam, RH lamp
Table 4
Electric circuits protected by fuses located within fuse block and relay of the vehicle passenger compartment
in «Luxe» version*
Protected circuit
Fuse No
Current force
