90
F13 10А Low beam, LH lamp
F14 15А Socket to connect additional devices in the trunk
F15 10А Rear window wiper
Rear window washer
F16 5А Driver door module
F17 Reserve
F18 Reserve
F19 Reserve
F20 Reserve
F21 10А High beam, RH lamp
F22 10А High beam, LH lamp
F23 10А RH fog light
F24 10А LH fog light
F25 15А FR seats heating
F26 5А ABS control unit/ESP control unit
F27 15А Cigar lighter
F28 15А Fuel pump
F29 20А Body electronics mainframe
Windshield wiper
Windshield washer
F30 Reserve
F31 7,5А Air conditioner compressor clutch
F32 7,5А Stop signal
Automatic gearbox controller
F33 25А ABS control unit/ESP control unit
F34 5А Instrument cluster
Diagnostic connector
F35 Reserve
F36 10А Audio signal (horn)
Protected circuit
Fuse No
Current force
Extension of table 4
