F37 10А Multimedia system
F38 Reserve
F39 Reserve
F40 Reserve
F41 50А Windshield heater
F42 Reserve
F43 50А Robotized gearbox controller
F44 30А Heater electric fan
Climate control system controller
F45 25А Rear window defroster
Outside mirrors defroster
F46 Reserve
Protected circuit
Fuse No
Current force
Extension of table 4
* It is specified the set of fuses for the top level of equipment – «Luxe» (depending on the set of options selected some fuses of this set in other versions
may not be used).
F1 15А Ignition coil
Nozzles
EMS control unit
F2 Reserve
F3 15А Alarm signaling
F4 20А Windshield washer
Windshield wiper
Table 5
Electric circuits protected by fuses located within fuse block and relay of the vehicle passenger compartment
in «Norm» and «Standard» versions
Protected circuit
Fuse No
Current force
