92
F5 7,5А Terminal clamp – 15 devices
F6 7,5А Backup light/Backup light relay*
Turn indicators
F7 7,5А Adsorber blowdown valve
Mass airflow sensor/pressure sensor
Phase sensor
Oxygen sensor
Tire Pressure Monitoring System control unit*
F8 Reserve
F9 5А Right side parking lights
F10 5А Left side parking lights
Instrument panel and buttons illumination
License plate lamp
Trunk compartment lamp
F11 5А Rear fog light
F12 10А Low beam, RH lamp
F13 10А Low beam, LH lamp
F14 15А Socket to connect additional devices in the trunk
F15 10А Rear window wiper*
Rear window washer*
F16 Reserve
F17 Reserve
F18 Reserve
F19 Reserve
F20 Reserve
F21 10А High beam, RH lamp
F22 10А High beam, LH lamp
F23 10А RH fog light
F24 10А LH fog light
F25 15А FR seats heating*
Protected circuit
Fuse No
Current force
Extension of table 5
