Before you remove your drill press from the packaging, select the area where you will use
your . machine. There are no hard-and-fast rules for its location, but below are a few guidelines.
1.
There should be an area at the front, back and sides of the machine suitable for the
length of material that you will be processing.
2.
Adequate lighting. The better the lighting, the more accurately and safely you will be able
to work.
3.
Solid floor. You should select a solid, flat floor, preferably concrete or something similar.
4.
Close to power source and, ideally, dust or debris collection.
A. Key & Chuck
B. Drift Key (arbor release tool)
C. Arbor
D. Eye Bolt for lifting
E. Table Height Adjustment Crank
F. Table Height Adjustment Handle
G. Feed Handle and Depth Stop/Lock
H. Hardware
I. Base
16
