Unpacking requires; tin snips, knife, and wrench.
Assembly requires; Hex Wrenches
Note: The machine is heavy, and if you have any doubt about the described procedure, seek
professional assistance. Do not attempt any procedure that you feel is unsafe or that you do
not have the physical capability of achieving.
Using the tin snips, cut the banding that is securing the machine to the pallet (if fitted).
WARNING: EXTREME CAUTION MUST BE USED BECAUSE THE BANDING WILL
SPRING AND COULD CAUSE INJURY.
Your drill press is shipped in custom packaging consisting of a heavy-duty cardboard box and
Styrofoam internal packaging.
Hint: Place the crate on a low, stable stand if lifting the machine with the help of others. Or
the machine can be lifted by the included Lifting Eye with a forklift.
Figure 10: Unpacking
1.
Open the cardboard box, remove the machine base, loose parts, and top foam insert.
Figure 11: Top insert Figure 12: Bottom insert
