Laguna Tools DS20 - Main Components & Controls

Q
R
S
T
A. Key, chuck J. Touch Screen Controls, PLC
B. Quill Control, Left K. Handle, Arbor Depth Control, Right
C. Laser, Left ½ L. RPM & Programming Control
D. Column M. E-Stop
E. Column Lock, Top 1/3 N. Chuck
F. Table Column Lock, 2/3 O. Table Elevation Handle
G. Table P. Table Insert
H. Colum Lock, Bottom 3/3 Q. Depth Scale
I. Base R. Depth Stop Lock
S. Laser, Right ½
T. Light
15
Main Components & Controls of the Drill Press
Figures 7 & 8: Components
J
K
L
M
N
O
P
A
B
C
D
E
F
G
H
I
