Laguna Tools DS20 - Parts List

DP20 Parts List
Ref No.
Part No.
Specifications
Description
Qty.
1
272001A
Machine head
1
2
272082S
Spring Cover Set
1
3
HS519
M5x10
Cross Round Head Screw
3
4
S307
3/16" x 1/2"
Flat Cross Head Screw
1
5
61103S
Spring Cover Set
1
8
272059A
Cover
1
9
HS223
Hex Socket Head Screw
3
10
MHK027
6x6x30
Key
1
11
272022A
Handle Body
1
12
W025
1/4"x 25
Washer
1
13
HS228
M6x10
Hex Socket Head Screw
1
14
272020B
Pinion Shaft
1
15
272069
Pinion Shaft base
1
16
HS519
M5 x 10
Cross Round Head Screw
3
17
272082S
Spring Base Set
1
18
HS520
M5x15
Cross Round Head Screw
3
19
S307
3/16" x 1/2"
Flat Cross Head Screw
1
20
272079S
Spring Cover Set
1
23
272059A
Cover
1
24
HS222
M5x30
Hex Socket Head Screw
3
25
2450051
4x13
Pin
1
26
272108
Limit Plate
1
27
HH001
2
Rivet
2
28
MHK027
6x6x30
Key
1
29
2450051
4x13
Pin
1
30
272106
Scale
1
31
HH001
2
Rivet
2
32
HS431
M8 x 16
Hex Socket Headless Screw
1
33
272070
Handle
1
34
272056A
Handle Rod
1
34-1
N001
1/2"
Hex Nut
1
34-2
HS421
M6 x 6
Hex Socket Headless Screw
1
34-3
272057
1
35
272022A
Handle Body
1
36
2450033A
Scale Base Set Screw
1
37
272145
Graduated Dial
1
38
2450063
Graduated Base Fixed Grip
1
39
W025
1/4"x25x2
Washer
1
45
