Identification/Serial label:
There is a plate at the back of the machine (below the main power switch) listing the
manufacturing data, including the serial number and model.
Figure 6: Identification Label
Motor (Not Shown):
The drill press is supplied with a 1-1/2 hp, 110V motor. The motor drives the quill and
Chuck through a pulley system. It is contained within the headstock.
