• E-STOP
An emergency STOP button (red) is located on the front of the headstock. Depress the red knob to
stop the machine. Twist the red button to reset and turn power back on. Only reset this button after
the emergency has been corrected.
Figure 4: Emergency-STOP (Twist to reset)
• Start/Stop.
The “ON/OFF” switch for starting the chuck or a program is located at the bottom, right of the Control
Panel.
Figure 5: Start/Stop button
