Fusion 3 Table Saw \ Setup \ Unboxing
NOTICE! The table saw will arrive secured to the wooden pallet.
1) Using the 13mm socket wrench provided or a standard wrench, loosen the bolts attaching the table saw to the pallet’s
metal L brackets.
Bolt
Removal
It is recommended that TWO OR MORE people assist in completing step two. However, one person can
complete the remaining unboxing steps without further assistance.
2)
Preferably with another person, slowly walk the table saw off the wooden pallet.
3)
For safe assembly, place the table saw in a well-lit, location free of any debris or obstructions.
Table Saw Mobility:
1. At the base of the table saw, there are two lock knobs (shown right) which allow the user to adjust the wheels located
beneath the table saw. Tightening the knobs will lock the table saw’s wheels. Loosen the knobs to allow wheels to
move. After the knobs have been adjusted, lift the table saw from the opposite end (like a wheelbarrow).
Knob
Location
Loosening Lock Knobs
