Fusion 3 Table Saw \ Setup \ Accessory Installation
Accessory Installation
The Fusion F3 table saw’s supports several accessories which help the machine to run smoothly and function properly. The
accessories which come with your table saw are: a dust collector hose, a set of fence hooks, and a tool caddy (located
underneath the table).
Add.
Required Tools:
None
Troubleshooting/Tips:
The writhing knife can be found already attached to the blade
upon arrival. Be sure the machine is off, when you attempt to
remove the writing knife from its position on the back of the
blade.
You will also need all the contents in the packages of:
Band clamp with hex bolt, flat washer, and hex nut. Fence hooks and hex bolts with flat washers.
Attaching
the
Dust
Collector
Hose:
1.
Attach a band clamp on the
mouth of the dust collector hose.
2.
Attach the hose to the dust port on the blade guard.
3.
Tighten the band clamp to secure the hose to the blade guard.
4.
Repeat steps one through three to attach the hose to the table saw’s 4” dust outlet.
