Fusion 3 Table Saw \ Replacement Parts Table \
© 2020 Laguna Tools
67
Key
Part No.
Description
Specifications
Qty
186
174711-000
Fix Plate
2
189
174772-000
Plate
1
190A
924854-000
Over Head Guards Assembly
36"
1
1
042620-015
Dust Hose
1.5 / 2700mm (I.D.)
1
2
174887-904
Brace
1
5
850913-000
Hardware Bag for 36" Over-
Head Guards
1
.1
001803-103
CAP Screw w/ Spring Washer
M8-1.25x25/8.2x13.7
1
.2
006001-049
Flat Washer
8.5x16x2.0
1
.3
008006-100
Hex Nut
M8-1.25 (13Bx6.5H)
1
.4
042622-003
Clamp
30-45 mm (I.D.)
2
190B
924855-000
Over Head Guards Assembly
52"
1
1
042620-016
Dust Hose
1.5 / 3700mm (I.D.)
1
2
174887-904
Brace
1
5
850913-000
Hardware Bag for 52" Over
Head Guards
1
.1
042622-003
Clamp
30-45 mm (I.D.)
2
.2
001803-103
CAP Screw w/ Spring Washer
M8-1.25x25/8.2x13.7
1
.3
006001-049
Flat Washer
8.5x16x2.0
1
.4
008006-100
Hex Nut
M8-1.25 (13Bx6.5H)
1
191
000304-102
Pan Head Screw
M6-1.0x10
2
192
950848-000
Tilt DRO Assembly
1
193
000805-101
Round Head Screw
M4-0.7x6
4
194
491221-000
Plate
1
195
175025-000
Fixed Plate
1
196
000301-201
Pan Head Screw
M3-0.5x6
1
197
000102-103
Cap Screw
M5-0.8x10
1
198
021808-000
Wire Clamp
NB-1419
1
199
474048-018
Cord
24AWG/4C/550mm
1
201
002504-701
Round Head Socket Lock
Screw
M4-0.7x10
1
202
006003-199
Flat Washer
4.3x14x2.0
1
203
381479-000
Bevel Gear
1
