Table D-5. Lake Shore RX-102A Rox™ Curve
Break-
point
logΩ
Temp.
(K)
Break-
point
logΩ
Temp.
(K)
Break-
point
logΩ
Temp.
(K)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
3.02081
3.02133
3.02184
3.02237
3.02294
3.02353
3.02411
3.02472
3.02537
3.02605
3.02679
3.02749
3.02823
3.02903
3.02988
3.03078
3.03176
3.03280
3.03393
3.03500
3.03615
3.03716
3.03797
3.03882
3.03971
3.04065
3.04164
3.04258
3.04357
3.04460
3.04569
3.04685
3.04807
3.04936
3.05058
40.0
38.8
37.7
36.6
35.5
34.4
33.4
32.4
31.4
30.4
29.4
28.5
27.6
26.7
25.8
24.9
24.0
23.1
22.2
21.4
20.6
19.95
19.45
18.95
18.45
17.95
17.45
17.00
16.55
16.10
15.65
15.20
14.75
14.30
13.90
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
3.05186
3.05322
3.05466
3.05618
3.05780
3.05952
3.06135
3.06330
3.06537
3.06760
3.06968
3.07190
3.07428
3.07685
3.07922
3.08175
3.08447
3.08786
3.09150
3.09485
3.09791
3.10191
3.10638
3.11078
3.11558
3.12085
3.12622
3.13211
3.13861
3.14411
3.14913
3.15454
3.16002
3.16593
3.17191
13.50
13.10
12.70
12.30
11.90
11.50
11.10
10.70
10.30
9.90
9.55
9.20
8.85
8.50
8.20
7.90
7.60
7.25
6.90
6.60
6.35
6.05
5.74
5.46
5.18
4.90
4.64
4.38
4.12
3.92
3.75
3.58
3.42
3.26
3.11
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
3.17838
3.18540
3.19253
3.20027
3.20875
3.21736
3.22675
3.23707
3.24842
3.26000
3.27169
3.28462
3.29779
3.31256
3.32938
3.34846
3.37196
3.39220
3.41621
3.44351
3.47148
3.50420
3.54057
3.58493
3.63222
3.68615
3.75456
3.82865
3.91348
4.01514
4.14432
4.34126
4.54568
4.79803
2.96
2.81
2.67
2.53
2.39
2.26
2.13
2.00
1.87
1.75
1.64
1.53
1.43
1.33
1.23
1.130
1.020
0.935
0.850
0.765
0.690
0.615
0.545
0.474
0.412
0.354
0.295
0.245
0.201
0.162
0.127
0.091
0.066
0.050
