Lake Shore Model 331 Temperature Controller User’s Manual
4.3 DISPLAY FORMAT AND SOURCE (UNITS) SELECTION
In the normal display, the display is divided into four user-configurable areas that can provide
temperature readings, setpoint display, and heater status. Figure 4-3 illustrates the display location
numbering and available selections for each location. To change Setpoint units and select Heater Out
Power or Current, refer to the description of
Control Setup in Paragraph 4.7. To change display
brightness, refer to Paragraph 4.18.
À 295.22½ Á 295.22½À 295.22½ Á 295.22½
 295.00½  295.00½ 0% Off 0% Off
Input A
Input B
None
Input A
Input B
None
Input A
Input B
Setpoint
None
Input A
Input B
Heater Out
None
Display Location 1:
Display Location 2:
Display Location 3:
Display Location 4:
C-331-4-3.eps
Figure 4-3. Display Format Definition
To configure a display location, press the Display Format key to display the following screen.
Select With °®
Display Location 1
Use the s or t key to increment or decrement through Display Locations 1 thru 4. For this example,
select Display Location 1, then press the
Enter key. You will see the following display
Select for Disp 1 °®
Display Input A
Use the s or t key to cycle between Input A, Input B, or None. For this example, select Input A then
press the
Enter key. You will see the following display
Select for Disp 1 °®
Source Temp K
Use the s or t key to cycle through the following data sources: Temp K, Temp C, Sensor, Linear, Min,
and Max. For this example, select Temp K then press the
Enter key.
NOTE: The sensor reading of the instrument can always be displayed in sensor units.
If a temperature response curve is selected for an input, its readings may also
be displayed in temperature.
Operation 4-5
