Lake Shore Model 331 Temperature Controller User’s Manual
Display Format (Continued)
With the settings from the previous example, Display Location 1 will resemble the following.
À 295.22½
The process is the same for the other three display locations. However, additional choices are provided
for Display Location 3 and 4, being Setpoint and Heater Out respectively.
In the following example, we will setup Display Location 3 to show the setpoint. Press the Display
Format
key.
Select With °®
Display Location 3
Use the s or t key to increment or decrement through Display Locations 1 thru 4. For this example,
select Display Location 3, then press the
Enter key. You will see the following display
Select for Disp 3 °®
Display Setpoint
Use the s or t key to cycle between Input A, Input B, Setpoint, or None. For this example, select
Setpoint then press the
Enter key.
With the settings from the previous example, and assuming you setup Display Location 1 detailed
above, the display will resemble the following.
À 295.22½ Á 295.22½
 0.000½
To change the setpoint units, refer to Control Setup, Paragraph 4.7.
4-6 Operation
