4.4 INPUT SETUP
The Model 332 supports a variety of temperature sensors sold by Lake Shore and other manufacturers.
An appropriate sensor type must be selected for each of the two inputs. If the exact sensor model is not
shown, use the sensor input performance chart in Table 4-1 to choose an input type with similar range
and excitation. For additional details on sensors, refer to the Lake Shore Temperature Measurement
and Control Catalog or visit our website at www.lakeshore.com.
Table 4-1. Sensor Input Types
Display Message
Input
Range
Excitation Sensor Type
Curve
Format
Coefficient
Lake Shore Sensors
*
Diode Silicon 2.5 V 10 µA Silicon Diode V/K Negative DT-4XX, DT-500, DT-670 Series
Diode GaAlAs
7.5 V 10 µA
Gallium-Aluminum-
Arsenide Diode
V/K Negative TG-120 Series
Platinum 100/250Ω
250
Ω
1 mA
100
Ω Plat. RTD <675K;
Rhodium-Iron RTD
Ω/K
Positive
PT-100 Series Platinum,
RF-800 Rhodium-Iron
Platinum 100/500Ω 500 Ω
1 mA
100 Ω Plat. RTD >675K
Platinum 1000Ω
5000
Ω
1 mA
1000 Ω Plat. RTD
Ω/K
Positive
—
NTC RTD 75mV 75Ω
†
75
Ω
1 mA
Negative Temperature
Coefficient (NTC) RTD
75 mV Max
log
Ω/K
Negative
Cernox™, High-Temperature
Cernox™, Carbon Glass™,
Germanium, Rox™, and
Thermox™
NTC RTD 75mV 750Ω
†
750
Ω
100 µA
NTC RTD 75mV 7.5kΩ
†
7.5 k
Ω
10 µA
NTC RTD 75mV 75kΩ
†
75 k
Ω
1 µA
NTC RTD Auto
†
Auto
Select
Auto
Select
Thermocouple 25mV
±25 mV NA Thermocouple
mV/K Positive
Chromel-AuFe (0.07%),
Type E (Chromel-Constantan),
Type K (Chromel-Alumel),
Type T (Copper-Constantan),
Thermocouple 50mV ±50 mV NA Thermocouple
* Refer to the Lake Shore Temperature Measurement and Control Catalog for complete details on all
Lake Shore Temperature Sensors.
†
Ranges may be selected automatically using NTC RTD Auto Range or selected manually.
4.4.1 Diode Sensor Input Setup
Diode type supports Silicon and Gallium-Aluminum-Arsenide (GaAlAs) diodes detailed in Table 4-1.
More detailed specifications are provided in Table 1-2. Input ranges are fixed to 0
– 2.5 V for silicon
diodes and 0
– 7.5 V for GaAlAs diodes. Both use a sensor excitation current of 10 µA.
To setup a diode sensor input, press the Input Setup key. The first screen appear as follows.
Select With °®
Input Setup Input A
Use the s or t key to toggle between Input A and B. Press the Enter key.
Select for InputA °®
Type Diode
